Hydraulic Desktop Injection Molding Machine 16 Tons

35 Gram Hydraulic Desktop Injection Molding Machine

Model:KCH35H
Dimensions(mm):1600*420*950
Power(KW):3.5
Net Weight:160kg
Gross Weight    :170kg
Package Size(mm)    :2300*660*920
Motor(KW):3
Mould Clamping Force    :160KN
Screw Diameter(mm):25
Working Voltage:220V/110V
Maximum injection volume    :35g
Max. Mould Size(mm):L184*W260*H300(customize)
Mould Locking Mode:Toggle
Injection Molding Method:Injection
Max.Injection Pressure:150Mpa
Maximum Injection Speed:150cm³/s
Mold Opening Stroke:110mm
Max Heating Temperature:350±1℃
Ejection Stroke(mm):50
Heating Stage:3
Applicable Material:PP PE ABS POMPA PC PLA TPE PMMA etc

Features
1.Compact structure and small footprint. Standardized industrial design, simple operation and easy to use
2.High precision and long life. Highly optimized mechanical mechanism and high-performance controller
3.Intelligent control, color touch screen, simple UI, multi-language settings, friendly operation
4.Servo motor, fast response, higher efficiency and low energy consumption
5.Stable performance. High-precision (±1℃) three-stage PID constant temperature control, three-stage barrel, precise temperature control.
6.Alloy barrel ( alloy material + quenching and tempering heat treatment),
anti-overflow plastic injection head
